Product Details
- Utilizes the industry’s lightest 199,000 BTU high efficiency condensing tankless heater
- Constructed of anodized aluminum frame for wall-mounted configurations
- Configure up to 96,000 BTU/h or up to 20 units together on a single rack system with multi-link system
- Redundant combustion system provides peace of mind & allows you to easily isolate for maintenance
- Easy field installation with three simple connections (cold water, hot water, and gas)
- Easily integrate storage into your design
- A. O. Smith common venting system means fewer wall penetrations and use schedule 40 PVC on intake and exhaust
- Warranty: 6 year limited heat exchanger, 5 year limited tankless parts and 1 year limited rack parts
The Wall Mount design allows you to link up to 20 water heaters together with multi-link system. Up to 96,000 BTU on a single rack system. Reduce installation costs with three simple connections (cold water, hot water, and gas). This model comes with 6-year limited heat exchanger warranty, a 5-year limited tankless parts warranty and a 1-year limited rack parts warranty.
Specifications
Tech Specs
Maximum BTUs
796,000
Power Source
GAS
Limited Tank Warranty
6 Years
Limited Parts Warranty
5 Years
Water Connection Size
0.75"
First Hour Rating
50 Gallons
ASME Certified
No
Destination Country
US
Fuel Source
NATURAL
Height to Gas Valve
9.88
Installation Type
OUTDOOR
Limited Heat Exchanger Warranty
6 Years
Minimum BTUs
60,000.00
Number of Water Heaters
4
Application
COMMERCIAL
Rack-Mounted
true
Shipping Height
26.13"
Shipping Length
95"
Shipping Width
70"
Side Loop
No
Voltage
120
Dimension & Venting
Type
Water Heater
Height
57"
Shipping Weight
540lbs
